Axcell WR Series Rack 1kVA - 3kVA

MODEL	AXCELL AX-1KWR
Phase	Single Phase with Ground
Capacity	1000VA/ 900W
INPUT
Nominal Voltage	208 / 220 / 230 / 240VAC
Voltage Range	120 - 300 VAC (Based on load at 50%)
Frequency Range	40Hz - 70Hz
Power factor	≥ 0.99 @ Nominal Voltage (100% load)
Input Connections
OUTPUT
Output Voltage	208 / 220 / 230 / 240VAC
AC Voltage Regulation (Batt. Mode)	± 1 %
Frequency Range (Synchronized Range)	47 - 53 Hz or 57 - 63 Hz
Frequency Range (Battery Mode)	50Hz or 60Hz ± 0.5%
Harmonic Distortion	≤ 3% THD (Linear Load) ; ≤ 6% THD (Non-linear Load)
Current Crest Ratio	3 : 1
Output Connections
TOPOLOGY
Transfer Time AC Mode to Batt. Mode	Zero
Transfer Time Inverter to Bypass	4ms (Typical)
Waveform (Batt. Mode)	Pure Sine Wave
BATTERIES
DC Voltage	24V
Battery Capacity	12V 9AH
Typical Recharge Time	4 hours to 90% capacity
Maximum Charging Current	1A
Charging Voltage	27.4 VDC ± 1%
EFFICIENCY
AC Mode	88%
Battery Mode	83%
SYSTEM
LCD Display	Load level, Battery level, AC mode, Battery mode, Bypass mode, and Fault indicators
Audible Alarm (Battery Mode)	Sounding every 4 seconds
Audible Alarm (Low Mode)	Sounding every seconds
Audible Alarm (Overload)	Sounding twice every seconds
Audible Alarm (Fault)	Continuously sounding
COMMUNICATIONS / MANAGEMENT
Smart RS232 / USB	Supports Windows® 2000 / 2003 / XP / Vista / 2008 / 7 / 8 / 10, Linux and MAC
Intelligent Slot	SNMP / AS400 Card
STANDARDS / APPROVALS
Compliances	CE, EN 62040-2, EN 61000-3-2, EN 61000-3-3
IP Rating	IP 20
ENVIRONMENT
Operating Humidity	20% - 90% (non-condensing)
Operating Temperature	0°C - 40°C
Acoustic Level at 1m	≤ 50 dB
PHYSICAL PROPERTIES
Dimensions (W x D x H) mm	438 x 310 x 88
Net weight (kg)	12

MODEL

AXCELL AX-1KWR

Phase

Single Phase with Ground

Capacity

1000VA/ 900W

INPUT

Nominal Voltage

208 / 220 / 230 / 240VAC

Voltage Range

120 - 300 VAC (Based on load at 50%)

Frequency Range

40Hz - 70Hz

Power factor

≥ 0.99 @ Nominal Voltage (100% load)

Input Connections

OUTPUT

Output Voltage

208 / 220 / 230 / 240VAC

AC Voltage Regulation (Batt. Mode)

± 1 %

Frequency Range (Synchronized Range)

47 - 53 Hz or 57 - 63 Hz

Frequency Range (Battery Mode)

50Hz or 60Hz ± 0.5%

Harmonic Distortion

≤ 3% THD (Linear Load) ; ≤ 6% THD (Non-linear Load)

Current Crest Ratio

3 : 1

Output Connections

TOPOLOGY

Transfer Time AC Mode to Batt. Mode

Zero

Transfer Time Inverter to Bypass

4ms (Typical)

Waveform (Batt. Mode)

Pure Sine Wave

BATTERIES

DC Voltage

24V

Battery Capacity

12V 9AH

Typical Recharge Time

4 hours to 90% capacity

Maximum Charging Current

Charging Voltage

27.4 VDC ± 1%

EFFICIENCY

AC Mode

88%

Battery Mode

83%

SYSTEM

LCD Display

Load level, Battery level, AC mode, Battery mode, Bypass mode, and Fault indicators

Audible Alarm (Battery Mode)

Sounding every 4 seconds

Audible Alarm (Low Mode)

Sounding every seconds

Audible Alarm (Overload)

Sounding twice every seconds

Audible Alarm (Fault)

Continuously sounding

COMMUNICATIONS / MANAGEMENT

Smart RS232 / USB

Supports Windows® 2000 / 2003 / XP / Vista / 2008 / 7 / 8 / 10, Linux and MAC

Intelligent Slot

SNMP / AS400 Card

STANDARDS / APPROVALS

Compliances

CE, EN 62040-2, EN 61000-3-2, EN 61000-3-3

IP Rating

IP 20

ENVIRONMENT

Operating Humidity

20% - 90% (non-condensing)

Operating Temperature

0°C - 40°C

Acoustic Level at 1m

≤ 50 dB

PHYSICAL PROPERTIES

Dimensions (W x D x H) mm

438 x 310 x 88

Net weight (kg)

MODEL	AXCELL AX-1KWR
Phase	Single Phase with Ground
Capacity	2000VA/ 1800W
INPUT
Nominal Voltage	208 / 220 / 230 / 240VAC
Voltage Range	120 - 300 VAC (Based on load at 50%)
Frequency Range	40Hz - 70Hz
Power factor	≥ 0.99 @ Nominal Voltage (100% load)
Input Connections
OUTPUT
Output Voltage	208 / 220 / 230 / 240VAC
AC Voltage Regulation (Batt. Mode)	± 1 %
Frequency Range (Synchronized Range)	47 - 53 Hz or 57 - 63 Hz
Frequency Range (Battery Mode)	50Hz or 60Hz ± 0.5%
Harmonic Distortion	≤ 3% THD (Linear Load) ; ≤ 6% THD (Non-linear Load)
Current Crest Ratio	3 : 1
Output Connections
TOPOLOGY
Transfer Time AC Mode to Batt. Mode	Zero
Transfer Time Inverter to Bypass	4ms (Typical)
Waveform (Batt. Mode)	Pure Sine Wave
BATTERIES
DC Voltage	48V
Battery Capacity	12V 9AH
Typical Recharge Time	4 hours to 90% capacity
Maximum Charging Current	1A
Charging Voltage	54.7 VDC ± 1%
EFFICIENCY
AC Mode	89%
Battery Mode	87%
SYSTEM
LCD Display	Load level, Battery level, AC mode, Battery mode, Bypass mode, and Fault indicators
Audible Alarm (Battery Mode)	Sounding every 4 seconds
Audible Alarm (Low Mode)	Sounding every seconds
Audible Alarm (Overload)	Sounding twice every seconds
Audible Alarm (Fault)	Continuously sounding
COMMUNICATIONS / MANAGEMENT
Smart RS232 / USB	Supports Windows® 2000 / 2003 / XP / Vista / 2008 / 7 / 8 / 10, Linux and MAC
Intelligent Slot	SNMP / AS400 Card
STANDARDS / APPROVALS
Compliances	CE, EN 62040-2, EN 61000-3-2, EN 61000-3-3
IP Rating	IP 20
ENVIRONMENT
Operating Humidity	20% - 90% (non-condensing)
Operating Temperature	0°C - 40°C
Acoustic Level at 1m	≤ 50 dB
PHYSICAL PROPERTIES
Dimensions (W x D x H) mm	438 x 410 x 88
Net weight (kg)	19

MODEL

AXCELL AX-1KWR

Phase

Single Phase with Ground

Capacity

2000VA/ 1800W

INPUT

Nominal Voltage

208 / 220 / 230 / 240VAC

Voltage Range

120 - 300 VAC (Based on load at 50%)

Frequency Range

40Hz - 70Hz

Power factor

≥ 0.99 @ Nominal Voltage (100% load)

Input Connections

OUTPUT

Output Voltage

208 / 220 / 230 / 240VAC

AC Voltage Regulation (Batt. Mode)

± 1 %

Frequency Range (Synchronized Range)

47 - 53 Hz or 57 - 63 Hz

Frequency Range (Battery Mode)

50Hz or 60Hz ± 0.5%

Harmonic Distortion

≤ 3% THD (Linear Load) ; ≤ 6% THD (Non-linear Load)

Current Crest Ratio

3 : 1

Output Connections

TOPOLOGY

Transfer Time AC Mode to Batt. Mode

Zero

Transfer Time Inverter to Bypass

4ms (Typical)

Waveform (Batt. Mode)

Pure Sine Wave

BATTERIES

DC Voltage

48V

Battery Capacity

12V 9AH

Typical Recharge Time

4 hours to 90% capacity

Maximum Charging Current

Charging Voltage

54.7 VDC ± 1%

EFFICIENCY

AC Mode

89%

Battery Mode

87%

SYSTEM

LCD Display

Load level, Battery level, AC mode, Battery mode, Bypass mode, and Fault indicators

Audible Alarm (Battery Mode)

Sounding every 4 seconds

Audible Alarm (Low Mode)

Sounding every seconds

Audible Alarm (Overload)

Sounding twice every seconds

Audible Alarm (Fault)

Continuously sounding

COMMUNICATIONS / MANAGEMENT

Smart RS232 / USB

Supports Windows® 2000 / 2003 / XP / Vista / 2008 / 7 / 8 / 10, Linux and MAC

Intelligent Slot

SNMP / AS400 Card

STANDARDS / APPROVALS

Compliances

CE, EN 62040-2, EN 61000-3-2, EN 61000-3-3

IP Rating

IP 20

ENVIRONMENT

Operating Humidity

20% - 90% (non-condensing)

Operating Temperature

0°C - 40°C

Acoustic Level at 1m

≤ 50 dB

PHYSICAL PROPERTIES

Dimensions (W x D x H) mm

438 x 410 x 88

Net weight (kg)

MODEL	AXCELL AX-1KWR
Phase	Single Phase with Ground
Capacity	3000VA/ 2700W
INPUT
Nominal Voltage	208 / 220 / 230 / 240VAC
Voltage Range	120 - 300 VAC (Based on load at 50%)
Frequency Range	40Hz - 70Hz
Power factor	≥ 0.99 @ Nominal Voltage (100% load)
Input Connections
OUTPUT
Output Voltage	208 / 220 / 230 / 240VAC
AC Voltage Regulation (Batt. Mode)	± 1 %
Frequency Range (Synchronized Range)	47 - 53 Hz or 57 - 63 Hz
Frequency Range (Battery Mode)	50Hz or 60Hz ± 0.5%
Harmonic Distortion	≤ 3% THD (Linear Load) ; ≤ 6% THD (Non-linear Load)
Current Crest Ratio	3 : 1
Output Connections
TOPOLOGY
Transfer Time AC Mode to Batt. Mode	Zero
Transfer Time Inverter to Bypass	4ms (Typical)
Waveform (Batt. Mode)	Pure Sine Wave
BATTERIES
DC Voltage	72V
Battery Capacity	12V 9AH
Typical Recharge Time	4 hours to 90% capacity
Maximum Charging Current	1A
Charging Voltage	82.1 VDC ± 1%
EFFICIENCY
AC Mode	90%
Battery Mode	88%
SYSTEM
LCD Display	Load level, Battery level, AC mode, Battery mode, Bypass mode, and Fault indicators
Audible Alarm (Battery Mode)	Sounding every 4 seconds
Audible Alarm (Low Mode)	Sounding every seconds
Audible Alarm (Overload)	Sounding twice every seconds
Audible Alarm (Fault)	Continuously sounding
COMMUNICATIONS / MANAGEMENT
Smart RS232 / USB	Supports Windows® 2000 / 2003 / XP / Vista / 2008 / 7 / 8 / 10, Linux and MAC
Intelligent Slot	SNMP / AS400 Card
STANDARDS / APPROVALS
Compliances	CE, EN 62040-2, EN 61000-3-2, EN 61000-3-3
IP Rating	IP 20
ENVIRONMENT
Operating Humidity	20% - 90% (non-condensing)
Operating Temperature	0°C - 40°C
Acoustic Level at 1m	≤ 50 dB
PHYSICAL PROPERTIES
Dimensions (W x D x H) mm	438 x 630 x 88
Net weight (kg)	29.3

MODEL

AXCELL AX-1KWR

Phase

Single Phase with Ground

Capacity

3000VA/ 2700W

INPUT

Nominal Voltage

208 / 220 / 230 / 240VAC

Voltage Range

120 - 300 VAC (Based on load at 50%)

Frequency Range

40Hz - 70Hz

Power factor

≥ 0.99 @ Nominal Voltage (100% load)

Input Connections

OUTPUT

Output Voltage

208 / 220 / 230 / 240VAC

AC Voltage Regulation (Batt. Mode)

± 1 %

Frequency Range (Synchronized Range)

47 - 53 Hz or 57 - 63 Hz

Frequency Range (Battery Mode)

50Hz or 60Hz ± 0.5%

Harmonic Distortion

≤ 3% THD (Linear Load) ; ≤ 6% THD (Non-linear Load)

Current Crest Ratio

3 : 1

Output Connections

TOPOLOGY

Transfer Time AC Mode to Batt. Mode

Zero

Transfer Time Inverter to Bypass

4ms (Typical)

Waveform (Batt. Mode)

Pure Sine Wave

BATTERIES

DC Voltage

72V

Battery Capacity

12V 9AH

Typical Recharge Time

4 hours to 90% capacity

Maximum Charging Current

Charging Voltage

82.1 VDC ± 1%

EFFICIENCY

AC Mode

90%

Battery Mode

88%

SYSTEM

LCD Display

Load level, Battery level, AC mode, Battery mode, Bypass mode, and Fault indicators

Audible Alarm (Battery Mode)

Sounding every 4 seconds

Audible Alarm (Low Mode)

Sounding every seconds

Audible Alarm (Overload)

Sounding twice every seconds

Audible Alarm (Fault)

Continuously sounding

COMMUNICATIONS / MANAGEMENT

Smart RS232 / USB

Supports Windows® 2000 / 2003 / XP / Vista / 2008 / 7 / 8 / 10, Linux and MAC

Intelligent Slot

SNMP / AS400 Card

STANDARDS / APPROVALS

Compliances

CE, EN 62040-2, EN 61000-3-2, EN 61000-3-3

IP Rating

IP 20

ENVIRONMENT

Operating Humidity

20% - 90% (non-condensing)

Operating Temperature

0°C - 40°C

Acoustic Level at 1m

≤ 50 dB

PHYSICAL PROPERTIES

Dimensions (W x D x H) mm

438 x 630 x 88

Net weight (kg)

29.3
